NETWORK
Protocol: TCP/IP, DHCP, DNS, NTP, UPnP
Incoming Bandwith: 80 Mbps
Outgoing Bandwidth: 60 Mbps
GENERAL
Package Contents:
*VIGI Network Video Recorder
*Power Adapter
*HDD Screws
*Mouse
*Quick Installation Guide
Operating Temperature: -10–55 °C
Dimensions( H X W X D ): 246.2 × 148.2 × 45 mm
Weight: 578.5 g
External Power Supply: 12V DC/1.5 A
Power Consumption:
*4.25 W (without disk)
*13.10 W (with disk)
VIDEO/IMAGE
Video Input: 16-Channel IP Video Input, up to 8 MP Resolution
Video Output:
*Recording Resolution: 8 MP/5 MP/ 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
HDMI/VGA
*Output Resolution: 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1680 × 1050/60Hz, 1440 × 900/60Hz
DECODING
Decoding Format: H.265+/H.265/ H.264+/H.264
Live View/Playback Resolution: 8 MP/5 MP/ 4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Capability: 1-ch @ 8 MP, 2-ch @ 4 MP, 4-ch @ 2 MP
HARD DISK
SATA: 1 SATA Interface
Capacity: Up to 10 TB
INTERFACES
Network Interface: 1 RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
USB Interface: 2× USB 2.0
