HARDWARE FEATURES |
Plug Type |
EU, UK, US |
Interfaces |
1 * 10/100M Ethernet Port (RJ45) |
Button |
RE (Range Extender) Button, Reset Button |
Dimensions (W X D X H) |
2.0x 1.3 x 2.6in. (52 x 34 x 65mm) |
Power Consumption |
About 3W |
Antenna |
2 *external |
WIRELESS FEATURES |
Wireless Standards |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Frequency |
2.4~2.4835GHz |
Signal Rate |
11n: Up to 300Mbps (dynamic) |
11g: Up to 54Mbps (dynamic) |
11b: Up to 11Mbps (dynamic) |
Reception Sensitivity |
270M: <-68dBm@10% PER |
130M: <-68dBm@10% PER |
108M: <-68dBm@10% PER |
54M: <-68dBm@10% PER |
11M: <-68dBm@8% PER |
6M: <-68dBm@10% PER |
1M: <-68dBm@8% PER |
Transmit Power |
< 20 dBm (EIRP) |
Wireless Modes |
Range Extender, AP Mode |
Wireless Functions |
Wireless MAC Address Filtering |
Domain Login Function |
Transmit Power Control |
Wireless Security |
64/128/152-bit WEP |
WPA-PSK / WPA2-PSK |
OTHERS |
Certification |
CE, RoHS |
Package Contents |
300Mbps Wi-Fi Range Extender TL-WA855RE |
RJ-45 Ethernet Cable |
Quick Installation Guide |
System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 8.1, 10, Mac OS, NetWare, UNIX or Linux. |
Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) |
Storage Temperature: -40°C~70°C (-40°F~158°F) |
Operating Humidity: 10%~90% non-condensing |
Storage Humidity: 5%~90% non-condensing |
