hAP lite
PŘEHLED/OVERVIEW
* hAP lite
* The home Access Point lite (hAP lite) is an ideal little device for your apartment, house or office.
* It supports button triggered WPS, for the convenience of not typing a complicated password when somebody wants to have wireless internet access, and can also be told to change to cAP mode and join a CAPsMAN centrally managed network by the push of a button.
* Of course, the device runs RouterOS with all the features, bandwidth shaping, firewall, user access control and many others.
* The hAP lite is equipped with a powerful 650MHz CPU, 32MB RAM, dual chain 2.4GHz onboard wireless, four Fast Ethernet ports and a RouterOS L4 license. USB power supply is included.
SPECIFIKACE/SPECIFICATIONS
Details
Product code
* RB941-2nD-TC
CPU nominal frequency
* 650 MHz
CPU core count
* 1
Size of RAM
* 32 MB
10/100 Ethernet ports
* 4
10/100/1000 Ethernet ports
* None
MiniPCI slots
* 0
MiniPCI-e slots
* 0
Wireless chip model
* QCA9533-BL3A
Wireless standards
* 802.11b/g/n
Number of USB ports
* 0
Power Jack
* 0
PoE in
* No
Supported input voltage
* 5 V - 5 V
PoE out
* No
Voltage Monitor
* No
PCB temperature monitor
* No
CPU temperature monitor
* No
License level
* 0
Antenna gain DBI
* 1.5
Current Monitor
* No
CPU
* QCA9533-BL3A
Max Power consumption
* 3W
SFP ports
* 0
SFP+ ports
* 0
Number of chains
* 2
Serial port
* None
