Dimensions(L x W x H)
|
99.8mm x 69.8mm x 7mm
|
|
Weight
|
52g
|
|
Interface
|
SATA III / 6Gbps
|
|
Flash Type
|
Micron ONFi 3.0 MLC (20nm)
|
|
Controller
|
Transcend TS6500
|
|
Seek Time
|
0.1 ms
|
|
Operating Temperature
|
0°C ~ 70°C
|
|
Shock Resistance
|
1500G, 0.5ms
|
|
Built-In ECC
|
40bits / 512 bytes
|
|
Capacity
|
32, 64, 128, 256, 512GB, 1TB
|
|
Endurance*
|
32GB: 45TBW
64GB: 80TBW
128GB: 150TBW
256GB: 380TBW
512GB: 550TBW
1TB: 1180TBW
|
Features:
l Advanced Global Wear-Leveling and Block management for reliability
l Advanced Garbage Collection
l With DDR3 DRAM cache
l Built-in ECC (Error Correction Code) functionality
l Advanced Power shield to prevent data loss when sudden power off
l Support Enhanced S.M.A.R.T. function
l Shock resistance
7mm Slim design
|
P/N
|
ATTO
|
CrystalDiskMark
|
IOmeter
|
|
Sequential R/W Performance
|
Sequential R/W Performance
|
4K Random R/W Performance
|
4K Random Read/Write
|
|
TS32GSSD370
|
260/40 MB/s
|
260/40 MB/s
|
90/40 MB/s
|
20,000/10,000
IOPS
|
|
TS64GSSD370
|
520/90 MB/s
|
510/80 MB/s
|
170/80 MB/s
|
40,000/20,000
IOPS
|
|
TS128GSSD370
|
570/170 MB/s
|
520/170 MB/s
|
280/170 MB/s
|
70,000/40,000
IOPS
|
|
TS256GSSD370
|
570/310 MB/s
|
520/310 MB/s
|
300/300 MB/s
|
75,000/75,000
IOPS
|
|
TS512GSSD370
|
570/470 MB/s
|
520/450 MB/s
|
300/300 MB/s
|
75,000/75,000
IOPS
|
|
TS1TSSD370
|
570/470 MB/s
|
500/460 MB/s
|
300/300 MB/s
|
75,000/75,000
IOPS
|
