Diagonal Size
55"
Panel Type
VA
Resolution
3,840 x 2,160
Pixel Pitch (HxV)
0.315 x 0.315
Brightness (Typ)
350cd/m2 (w/o glass), 220cd/m2 (w/glass)
Contrast Ratio
4000:1(without glass)
Viewing Angle (H/V)
178/178
Response Time
8ms
Colour Gamut
72%
Glass Haze
2%(without glass)
H-Scanning Frequency
30~81 khz
Maximum Pixel Frequency
594Mhz
V-Scanning Frequency
48~75 Khz
Dynamic Contrast Ratio
N/A
Operation Time Support
16/7
Connectivity
HDMI In
2
DP In
1
DVI In
N/A
Version of HDMI
2
Version of DP
1.2
Version of HDCP
2.2
Tuner In
N/A
USB
1(Rear), 3 (with optional front tray, Internal 1, External 1, USB-C 1)
IR In
N/A
HDBaseT In
N/A
Audio In
N/A
Audio Out
Stereo Mini Jack
Video Out
N/A
Power Out
N/A
RS232 In
Yes
RS232 Out
N/A
RJ45 In
Yes
RJ45 Out
N/A
WiFi
Yes
3G Dongle
N/A
Bluetooth®
Yes
Power
Power Supply
AC100-240V 50/60Hz
Power Consumption (Off Mode)
N/A
Power Consumption (On Mode)
154W
Power Consumption (Sleep Mode)
0.5W
Dimension
Set Dimension (WxHxD)
1297.4 x 768.2 x 59.9 mm
Package Dimension (WxHxD)
1464 x 915 x 190 mm
Weight
Set Weight
28.6 kg
Package Weight
35.9 kg
Operation Conditions
Temperature
0?~40?
Humidity
10 ~ 80%, non-condensing
Mechanical Specification
VESA Mount
400 x 400 mm
Bezel Width
26.2
Frame Material
Plastic
Optional Feature
Touch
Yes
Mount
Yes(Model Name : WMN-4277SF)
Stand
Yes(Model Name : STN-WM55R)
SoC
OS Version
Tizen 6.5
Flash Memory Size
32GB
