TS-431
4-bay home & SOHO NAS for personal cloud with file sharing, backup, and multimedia experience
Features
-Build a private cloud-based notebook and share with friends and colleagues with the Notes Station and Qnotes mobile app
-Organize & manage files and backup tasks in one centralized location
-Synchronize files between computers, laptops, and mobile devices
-Archive, manage, enjoy and share media collections with the dedicated Photo Station, Video Station and Music Station apps
-Enjoy family videos, movies, music, and photos on your TV with DLNA and AirPlay streaming
-Transcode videos offline and enjoy smooth video streaming even when your network connection is restricted
-Create a 24/7 surveillance center for your home/small office
Hardware specification
CPU Freescale™ ARM® Cortex®-A9 dual-core 1.2GHz processor with hardware encryption engine
DRAM 512MB
Flash Memory 512MB eMMC
Hard Disk Drive 4 x 3.5" or 2.5" SATA 6Gb/s, SATA 3Gb/s HDD or SSD
NOTE:
The system is shipped without HDD.
For the HDD compatibility list, please visit http://www.qnap.com/compatibility
Hard Disk Tray 4 x Hot swappable tray
LAN Port 2 x Gigabit RJ-45 Ethernet port
LED Indicators Power, Status, LAN, USB, HDD1-4
USB
3 x USB 3.0 port (front: 1, rear:2)
Support USB printer, pen drive, USB hub (front), and USB UPS etc.
Buttons Power, USB One-Touch-Copy, reset
Alarm Buzzer System warning
Secure Design Kensington security slot for theft prevention
Fan 1 x quiet cooling fan (12 cm, 12V DC)
Form Factor Tower
Dimensions
177(H) x 180(W) x 235(D) mm
6.97(H) x 7.09(W) x 9.25(D) inch
Weight Net: 3 kg (6.61 lbs); Gross: 4.3 kg (9.48 lbs)
Power Consumption (W)
HDD standby: 14.84W
In operation: 33.75W
(with 2TB HDDs installed)
Temperature 0-40°C
Humidity 5~95% RH non-condensing, wet bulb: 27°C
Power Supply External Power Adapter, 90W, 100-240V
