System Requirements
Audio with 3.5 mm or RCA output including:•Computer running on any major operating system (Windows®, Mac®, Chromebooks™)
•Smartphones
•Tablets
•Televisions
•MP3 players
•Gaming Consoles: PlayStation®3, Xbox 360®
Warranty Information
2-Year Limited Hardware Warranty
Package Contents
•Right satellite
•Left satellite
•Subwoofer
•3.5 mm to 3.5 mm cable
•User documentation
Part Number
Dimensions
Satellite:Height: 170 mm (6.69 in) Width: 100 mm (3.93 in ) Depth: 85 mm (3.34 in) Weight: 525 g (1.16 lbs)
Subwoofer:Height: 265 mm (10.43 in) Width: 255 mm (10.03 in) Depth: 195 mm (7.67 in) Weight: 4.0 kg (8.82 lbs)
Control podHeight: 55 mm (2.16 in) Width: 72 mm (2.83 in) Depth: 72 mm (2.83 in) Weight: 200 g (7 oz)
Cable Length:•Power/Charging Cable: 200 cm (6.6 ft.)
•Right satellite to subwoofer: 185 cm (6.1 ft.)
•Left satellite to subwoofer: 185 cm (6.1 ft.)
•Control pod hard wired cable: 185 cm (6.1 ft.)
Technical Specifications
Speaker Type: 2.1 Power Type: AC Power Rating (RMS):•60 watts
•Satellite: 2 x 15 watts (into 8 ohms, @1 KHz, @10% THD)
•Subwoofer: 30 watts (into 4 ohms, @100Hz, @10% THD)
Power Adapter: 100 - 240V (50/60Hz) Connections:•Inputs: Stereo RCA, 3.5 mm auxiliary inputs
•Headphone jack: 3.5 mm
Driver Size:•Satellite: 66 mm (2.6 in) full range phase plug speaker drivers
•Subwoofer: 133 mm (5.25 in) front-firing dome driver
Sound Pressure Level (SPL Max): >97 dBA Signal -to-Noise Ratio (SNR):•Satellites: 80 dB, A-weighted
•Subwoofer: 80 dB, A-weighted
Frequency response: 55 Hz – 20 kHz Input Impedance: 8Kohm Audio Controls: Bass,Volume,ON/OFF on control pod Sensitivity:•Satellites: 450mV
•Subwoofer: 200mV
