| Part Number | |
| 63D1RAT1EU | |
| |
| PERFORMANCE | |
| Display Size | 31.5" |
| View Area | 697.3x392.2 mm |
| Panel | In-Plane Switching |
| Backlight | WLED |
| Aspect Ratio | 16:9 |
| Resolution | 3840x2160 |
| Pixel Pitch | 0.182x0.182 mm |
| Dot / Pixel Per Inch | 140 dpi |
| View Angle (H / V) | 178° / 178° |
| Response Time | 4 ms (Extreme mode) / 6 ms (Normal mode) |
| Color Support | 1.07 Billion |
| Refresh Rate | 60Hz |
| Brightness | 350 nits |
| Contrast Ratio | 1000:1 |
| Color Gamut | 100% sRGB, 95% DCI-P3 |
| Screen Surface Treatment | Anti-glare |
| Curvature | None |
| Camera | Modular Camera Support |
| Microphone | None |
| Speakers | Modular Speaker Support |
| Power Consumption (Typical / Maximum) | 29.5W / 193.7W |
| Power Adapter | Integrated |
| Touchscreen | None |
| Smart System | None |
| |
| DESIGN | |
| Stand | Supports -5° to +23.5° tilt, left & right 45 swivel, -90° to +90° pivot, up to 155mm lift |
| Case Color | Raven Black |
| Side Bezel Width | 2 mm |
| Dimensions with Stand (HxWxD) | 599.5x714.2x234.6 mm / 23.6x28.12x9.24 inches |
| Weight (Including Stand) | 10.1 kg / 22.2 lbs. |
| Mounting | Supports VESA mount 100mm |
| ThinkCentre M Series Support | Tiny Support |
| |
| PORT | |
| 1x Thunderbolt 4 In (Up to 100W), USB upstream | |
| 1x Thunderbolt 4 Out (Up to 27W), USB downstream | |
| 1x HDMI 2.0 | |
| 1x DisplayPort™ 1.4 | |
| 1x USB-B 3.2 Gen 1, USB upstream | |
| 4x USB 3.2 Gen 1 (1x BC 1.2), USB downstream | |
| 1x Ethernet (RJ-45) | |
| 1x audio-out (3.5mm) | |
| |
| SERVICE | |
| Base Warranty | 3-year |
| |
| CERTIFICATIONS | |
| Environmental Certification | ENERGY STAR Certified, TCO 9.0, TCO Edge 2.0, EPEAT Gold, RoHS |
| Ergonomic Certification | Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland Eye Comfort |
| Sync Technology | None |
| |
| SOFTWARE | |
| Operating System | Support Windows 10, Windows 11 |
| |
| ACCESSORIES | |
| Video Cables | HDMI cable, DP cable, USB-A to USB-b cable, Thunderbolt cable |
| |
| SPECIAL FEATURES | |
| Factory Calibration: Avg. Delta E<2 | |
| Picture In Picture (PIP) / Picture By Picture (PBP) Support | |
| KVM Switch | |
| Natural Low Blue Light | |
| Lenovo® ThinkColour (Lenovo Display Control Center) Support ThinkColour can only be used with Windows 10 and Windows 11 | |
| Smart Power The Smart Power function intelligently detects overall power consumption and dynamically manages the power delivery to each device | |
