| CPU |
Intel®
Socket LGA1700 for 13th Gen Intel® Core™ Processors & 12th
Gen Intel® Core™, Pentium® Gold and Celeron® Processors |
| Supports
Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max
Technology 3.0** |
| * Refer to
www.asus.com
for CPU support list. |
| ** Intel®
Turbo Boost Max Technology 3.0 support depends on the CPU
types. |
| Chipset |
Intel® B760 Chipset |
| Memory |
4 x DIMM,
Max. 128GB, DDR5
7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800
MHz Non-ECC, Un-buffered Memory* |
| Dual
Channel Memory Architecture |
| Supports
Intel® Extreme Memory Profile (XMP) |
| OptiMem II |
| * Supported memory types, data
rate(Speed), and number of DRAM modules vary depending on
the CPU and memory configuration, for more information refer
to www.asus.com for memory support list. |
| * Non-ECC, un-buffered DDR5 memory
supports On-Die ECC function. |
| Graphics |
1 x DisplayPort** |
| 1 x HDMI®
port*** |
| * Graphics
specifications may vary between CPU types. Please refer to www.intel.com
for any updates. |
| **Supports max. 8K@60Hz as
specified in DisplayPort 1.4. |
| ***Supports 4K@60Hz as specified in
HDMI 2.1. |
| Expansion Slots |
Intel® 13th
& 12th Gen Processors* |
| 1 x PCIe
5.0x16 slot (supports x16 mode)** |
| Intel®B760
Chipset** |
| 1 x PCIe
3.0 x16 slot (supports x4 mode)*** |
| 2 x PCIe
3.0 x1 slots |
| - To ensure
compatibility of the device installed, please refer to https://www.asus.com/support/ for the list of supported peripherals. |
| Storage |
Total supports 3 x
M.2 slots and 4 x SATA 6Gb/s ports* |
| Intel® 13th & 12th Gen Processors |
| M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0
x4 mode) |
| Intel® B760 Chipset** |
| M.2_2 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 4.0 x4 ) |
| M.2_3 slot (Key M), type 2242/2260/2280
(supports PCIe 4.0 x4 ) |
| 4 x SATA 6Gb/s ports |
| * Intel® Rapid Storage Technology supports SATA
RAID 0/1/5/10. |
| Ethernet |
1 x Intel® 2.5Gb
Ethernet |
| ASUS
LANGuard |
| Wireless & Bluetooth® |
Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band*
Supports Intel® Double Connect Technology
Bluetooth® v5.3**
* WiFi 6E 6GHz regulatory may vary between countries.
** The Bluetooth version may vary, please refer to the Wi-Fi
module manufacturer´s website for the latest specifications. |
| USB |
Rear USB (Total 8 ports) |
| 1 x USB
3.2 Gen 2x2 port (1 x USB Type-C®) |
| 1 x USB
3.2 Gen 2 port (1 x Type-A) |
| 6 x USB
3.2 Gen 1 ports (6 x Type-A) |
| Front USB
(Total 7 ports) |
| 1 x USB
3.2 Gen 2 connector |
| 1 x USB
3.2 Gen 1 header supports 2 additional USB 3.2 Gen 1 ports |
| 2 x USB
2.0 headers support 4 additional USB 2.0 ports |
| Audio |
ROG SupremeFX 7.1 Surround Sound High
Definition Audio CODEC ALC4080
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel
Jack-retasking
- High quality 120 dB SNR stereo playback output and 113 dB
SNR recording input
- Supports up to 32-Bit/384 kHz playback |
| Audio
Features |
| -
SupremeFX Shielding Technology |
| - Savitech
SV3H712 AMP |
| - Rear
optical S/PDIF out port |
| - Premium
audio capacitors |
| - Audio
cover |
| Back Panel I/O Ports |
1 x USB 3.2 Gen 2x2
port (1 x USB
Type-C®) |
| 1 x USB 3.2 Gen 2 port (1 x Type-A) |
| 6 x USB 3.2 Gen 1 ports (6 x Type-A) |
| 1 x DisplayPort |
| 1 x HDMI® port |
| 1 x Wi-Fi Module |
| 1 x Intel® 2.5Gb Ethernet port |
| 5 x Audio jacks * |
| 1 x Optical S/PDIF out port |
| 1 x BIOS FlashBack™ button |
| 1 x Clear CMOS button |
| *The rear
panel Lime (Line out) port does not support spatial audio.
If you wish to use spatial audio make sure to connect your
audio output device to the audio jack on the front panel of
your chassis. |
| Internal I/O Connectors |
Fan and Cooling
related |
| 1 x 4-pin CPU Fan header |
| 1 x 4-pin CPU OPT Fan header |
| 1 x 4-pin AIO Pump header |
| 4 x 4-pin Chassis Fan headers |
| Power related |
| 1 x 24-pin Main Power connector |
| 1 x 8-pin +12V Power connector |
| 1 x 4-pin +12V Power connector |
| Storage related |
| 3 x M.2 slots (Key M) |
| 4 x SATA 6Gb/s ports |
| USB |
| 1 x USB 3.2 Gen 2 connector (supports USB Type-C® ) |
| 1 x USB 3.2 Gen 1 header supports 2 additional
USB 3.2 Gen 1 ports |
| 2 x USB 2.0 headers support 4 additional USB 2.0
ports |
| Miscellaneous |
| 3 x Addressable Gen 2 headers |
| 1 x Aura RGB header |
| 1 x Front Panel Audio header (AAFP) |
| 1 x 20-3 pin System Panel header with Chassis
intrude function |
| 1 x Thermal Sensor header |
| 1 xThunderbolt™ (USB4®) header |
| Special Features |
Extreme Engine Digi+ |
| - 5K Black Metallic
Capacitors |
| ASUS
Q-Design |
| - M.2
Q-Latch |
| - PCIe
Slot Q-Release |
| - Q-DIMM |
| - Q-LED
(CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow
green]) |
| - Q-Slot |
| ASUS
Thermal Solution |
| - M.2
heatsink |
| - VRM
heatsink |
| ASUS EZ
DIY |
| - BIOS
FlashBack™ button |
| - BIOS
FlashBack™ LED |
| - Clear
CMOS button |
| - CPU
Socket lever protector |
| - ProCool |
| -
Pre-mounted I/O shield |
| - SafeSlot |
| - SafeDIMM |
| Aura Sync |
| - Aura RGB
header |
| -
Addressable Gen 2 headers |
| Software Features |
ROG Exclusive Software |
| -
GameFirst VI |
| - ROG
CPU-Z |
| - Sonic
Studio III + Sonic Studio Virtual Mixer + Sonic Suite
Companion |
| - Sonic
Radar III |
| - DTS®
Sound Unbound |
| ASUS
Exclusive Software |
| Armoury
Crate |
| - AIDA64
Extreme (60 days free trial) |
| - Aura
Creator |
| - Aura
Sync |
| - Fan
Xpert 4 |
| - Power
Saving |
| - Two-Way
AI Noise Cancellation |
| AI Suite 3 |
| -
Performance And Power Saving Utility |
| - DIGI+
VRM |
| - PC
Cleaner |
| MyAsus |
| Norton 360
for Gamers |
| WinRAR |
| UEFI BIOS |
| ASUS EZ
DIY |
| - ASUS
CrashFree BIOS 3 |
| - ASUS EZ
Flash 3 |
| - ASUS
UEFI BIOS EZ Mode |
| MemTest86 |
| BIOS |
256
Mb Flash ROM, UEFI AMI BIOS |
| Manageability |
WOL
by PME |
| Accessories |
Cables |
| 2 x SATA 6Gb/s cables |
| Additional Cooling Kit |
| 1 x Thermal pad for M.2 |
| Miscellaneous |
| 1 x ASUS Wi-Fi moving antennas |
| 1 x Cable ties package |
| 1 x M.2 Q-Latch package |
| 2 x M.2 Rubber Package |
| 1 x ROG key chain |
| 1 x ROG Strix stickers |
