| Part No | 90NX06R1-M00JH0 |
| Model Name | B5404CMA-Q50492X |
| EAN Code | 4711387602911 |
| UPC Code | 197105602915 |
| WEEE | 1.047 |
| BASE UNIT | VSNX06R1-BU2271 |
| |
| Operating System | Windows 11 Pro - ASUS recommends Windows 11 Pro for business |
| Office | 1-month trial for new Microsoft 365 customers. Credit card required. |
| LCD cover-material | Aluminum |
| LCD cover-color | Star Black |
| Top case-material | Aluminum + MgAl |
| Top case-color | Star Black |
| Bottom case-material | Aluminum |
| Bottom case-color | Star Black |
| Military grade | US MIL-STD 810H military-grade standard |
| Panel Size | 14.0-inch |
| Backlit | LED Backlit |
| Brightness | 300nits |
| Resolution | WUXGA (1920 x 1200) 16:10 |
| Glare | Anti-glare display |
| Color gamut | NTSC: 45% |
| View angle(H/V) | 178/178 |
| Response time(Typ/Max) (ms) | 20/25 |
| Refresh rate | 60Hz |
| Contrast (Typ) | 1000:1 |
| Touch Panel | Non-touch screen |
| Screen-to-body ratio | 84 % |
| IPS-level | Wide view |
| Processor | Intel® Core™ Ultra 5 Processor 125H 1.2 GHz (18MB Cache, up to 4.5 GHz, 14 Cores); Intel® AI Boost NPU |
| Neural processor | Intel® AI Boost NPU |
| Chipset | N/A |
| Discrete/Share | Share |
| Integrated GPU | Intel® Arc™ Graphics(available for Intel® Core™ Ultra H 5/7/9 with dual channel memory) |
| VRAM | N/A |
| How to upgrade memory | Upgradable; Need to remove bottom/top case |
"| Expansion Slot(includes used) | 2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
"
| On board memory | N/A |
| DIMM Memory | 16GB DDR5 SO-DIMM *2 |
| Total System Memory | DDR5 32GB |
| Storage | 1TB M.2 2280 NVMe™ PCIe® 4.0 SSD |
| SSD Cache | N/A |
"| Front-facing camera | 1080p FHD camera with IR function to support Windows Hello
With privacy shutter |
"
| Wireless | Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth® 5.3 Wireless Card |
| 3G/4G | 4G LTE support (in selected territories) |
| NumberPad | N/A |
| ScreenPad | N/A |
| FingerPrint | FingerPrint |
| Keyboard type | Backlit Chiclet Keyboard |
"| I/O ports | 2x USB 3.2 Gen 2 Type-A
2x Thunderbolt™ 4, compliant with USB4, supports display / power delivery
1x HDMI 2.1 TMDS
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet
SIM card slot
Smart card reader |
"
"| Audio | Dolby Atmos
Built-in array microphone |
"
| Voice control | with Cortana support |
| Battery | 63WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter | TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal |
| Dimension (WxHxD) | 31.37 x 22.68 x 1.89 ~ 1.90 cm (12.35" x 8.93" x 0.74" ~ 0.75") |
| Weight (with Battery) | 1.46 kg (3.22 lbs) |
| Weight (w/o Battery) | 1.22 kg (2.69 lbs) |
"| Security | Fingerprint sensor integrated with Power Key
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS setup user password
Computrace ready from BIOS
HDD User Password Protection and Security
Trusted Platform Module (TPM) 2.0
N/A |
"
| Antivirus | N/A |
"| MyASUS feature | System diagnosis
Battery health charging
Fan Profile
Splendid
Tru2Life
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS |
"
"| Built-in Apps | MyASUS
McAfee |
"
"| Disclaimer for Built-in Apps | Built-in Apps vary from OS SKU.
*MyASUS/McAfee don´t support in Pure OS/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
"
| Reparability Index (for France) | 8.4 |
"| Ecolabels & Compliances | EPEAT Gold
Energy star 8.0
FSC Recycled
REACH
RoHS |
"
| Warranty | 3Y ON-SITE NBD |
"| Battery warranty | Commercial NB Battery warranty follow system warranty.
* BP series Battery warranty 4Y-5Y by WEP option
* Chromebook series Battery warranty 2Y-5Y by WEP option
|
"
